Yovon Pure Motor Fireworks Paper Tube Rolling Speed Machine CS-12-B1 Type
NO.:
Catalog:Fireworks paper tube making machine
Specifications:
Contain:
Describe:
Technical parameters CS-12-B type
Number of roll paper 3-15 layer
Tube ID 8.5-25 mm
tube thickness 1-5mm
Applicable paper gram 180-250gsm
Max. Paper tube length 620mm* max feed into paper 1300mm
Roll core mold fixed Three claws chuck
Winding head 2 rolls of belts
Cutting mode Single circular knife cutting
Glue way Single sides
operation 1 person
Paper delivery speed 30-35 sheets/min
Speed control transducer
Applicable glue white glue/Tapioca starch glue
Input Total power 8.5kw/ 380V 50HZ
Working no air pressure 1 Variable-speed motor,0.75kw
2 servo motor,1.5kw
6 servo motor,0.75kw
weight 1400 kg
Main frame size 2800*2760*1560mm

Yovon Fireworks CS-12-B2 Speed Kraft Paper Tube Making with Cutting Machine Pure Motor with Grind Edge No Air Compresspor
NO.:
Catalog:Fireworks paper tube making machine
Specifications:CS-12-B2
Contain:
Describe:Technical parameters CS-12-B2 type Number of roll paper 3-15 layer Tube ID 8.5-25 mm tube thickness 1-5mm Applicable paper gram 180-250gsm Max. Paper tube length 620mm* max feed into paper 1300mm Roll core mold fixed Three claws chuck Winding head 2 rolls of belts Cutting mode Single circular knife cutting Glue way Single sides operation 1 person Paper delivery speed 30-35 sheets/min Speed control transducer Applicable glue white glue/Tapioca starch glue Input Total power 8.5kw/ 380V 50HZ Working no air pressure,Pure motor 1 Variable-speed motor,0.75kw 2 servo motor,1.5kw 6 servo motor,0.75kw 1 grind edge motor weight 1400 kg Main frame size 2800*2760*1560mm
